Description
Elastorene, fast-setting waterproofing material offering high performance and elasticity. In addition to its high elasticity properties, this material also has excellent adherence to metal and concrete surfaces.
Usage Areas
• Building foundations,
• Basement floor and walls,
• Sustaining walls,
• Tunnels and canals,
• Closed roof and porches
Application
• As a cold applied material, Elastorene should not be used with thinner.
• It can be applied with a bitumen brush, airless gun or trowel.
• Depending on weather conditions, it dries in approximately 5-6 hours.
• It should not be applied in rainy weather, and at temperatures below +5°C.
• Next layer should not be applied before preceding one completely dries.
• For the applications requiring durability against higher water pressure, and on cracked surfaces, it must be reinforced with materials such as polyester felt, reinforcing fabric, fibermesh, etc.
Advantages
• Easy to apply material.
• Provide a seamless insulation layer.
• As a water-based material, it is environment friendly.
• Do to its inflammable and non-toxic characteristics it can be safely used indoor areas.
• It provides permanent elasticity.
• Ready to use.
• As a cold applied material it does not require heating and thinning.
• It has ability to cover up capillary cracks.
• Instantly applicable, no need to wait for concrete curing.
Surface Preparation
• The application surface should be without dust, rust, dirt, grease and oil and the loose parts should be scrapped out.
• Emilkote® bitumen emulsion on concrete surfaces and Emülzer® C on metal surfaces can be used as primer.
• The sharp corners or horizontal-vertical joints subject to cracking should be rounded with Emülzer® Bituminous Fillet.
• The large pores and the cracks should be filled with Emülderz® bituminous elastic joint filler.
Consumption
1 kg/m² for each layer. Min. 2 coats.
Packaging
23 kg Metallic Pail - 33 Pails / Pallet
BASE |
Elastomeric polymer resin reinforced bitumen emulsion |
THINNER |
Water |
COLOUR |
The color of Petroleum to brown before use, Black after drying |
CONSISTENCY |
Viscous Liquid (thixotropic) in packaging, fluid liquid when it is mixed |
DENSITY |
1,02 kg/dm3 |
APPLICATION TEMPERATURE |
Between (+5°C) / (+40°C) |
SERVICE TEMPERATURE |
Between (-10°C) / (+60°C) |
SOLID CONTENT |
60% |
DRY FILM THICKNESS |
2,5 – 4 mm |
FLASH POINT |
Not flammable |
CURING TIME |
Touching :1 hour Full Drying :5-6 hours Test :5 days |
CARBONDIOXIDE PERMEABILITY |
>50 m (TS EN 1062-6) |
WATER VAPOUR PERMEABILITY |
5m<SD<50m (Class II) (TS EN ISO 7783-2:2002) |
WATER PERMEABILITY |
<0,1 kg/m2.h0,5 (TS EN 1062-3) |
RESISTANCE TO WATER PRESSURE |
>1 atm, 24 hours (DIN 52123) |
ELONGATION AT BREAK |
>1200% |
FLEXIBILITY AND CRACK BRIDGE AT LOW TEMPERATURE |
PASSED (TS EN 15812) |
RESISTANCE TO SOIL BACTERIAL (30 DAYS, 400C) |
PASSED (ASTM D 3080) |
BOND STRENGTH |
>0,8 N/mm2 (TS EN 1542:2001) |
(At 23°C and %50 relative humidity. Higher temperatures decrease; lower temperatures increase the times given.)
